Interface ports
100H:
8 x 1-GbE Ethernet
100HP:
1 x PoE+ Ethernet (802.3at, 30W max.)
USB 3.0 ports
1
Console port
Yes (RJ-45)
Rack-mountable
-
Fanless
Yes
SPI firewall throughput (Mbps)*2
3,000
VPN throughput (Mbps)*3
750
IPS throughput (Mbps)*4
1,500
Anti-Malware throughput (Mbps)*4
UTM throughput (Anti-malware & IPS, Mbps)*4
Max. TCP concurrent sessions*5
300,000
Max. concurrent IPsec VPN tunnels*6
50
Recommended gateway-to-gateway IPsec VPN tunnels
20
Concurrent SSL VPN users
25
VLAN interface
16
Max. Concurrent devices logins*7
64
Anti-Malware
IPS
Application Patrol
Web filtering
Reputation Filter
SecuReporter
Sandboxing
Device Insight
Secure WiFi*9
VPN
IKEv2, IPSec, SSL
SSL (HTTPS) inspection
Two-Factor Authentication
Nebula Centralized Management
Power input
100H: 12V DC, 2A max.
100HP: 19V DC,3.42A
Max. power consumption (Watt Max.)
100H: 17
100HP: 51.2
Heat dissipation (BTU/hr)
100H: 40.365
100HP: 194.5
Item
Dimensions (WxDxH)(mm/in.):
216 x 143 x 33/8.50 x 5.80 x 1.30
Weight (kg/lb.):
100H: 1.04/2.29
100HP: 1.05/2.31
Packing
278 x 189 x 99/10.94 x 7.44 x 3.89
100H: 1.62/3.57
100HP: 1.91/4.21
Included accessories
Power adapter
Power cord (100HP)
RJ-45 - RS-232 cable for console connection
Operating
Temperature: 0°C to 40°C / 32°F to 104°F
Humidity: 10% to 90% (non-condensing)
Storage
Temperature: -30°C to 70°C / -22°F to 158°F
Humidity: 10% to 90%(non-condensing)
MTBF (hr)
40°C/ 289845.2327 hr
25°C/ 518347.4294 hr
40°C/ 291183.7887 hr
25°C/ 550382.5753 hr
Acoustic noise
EMC
FCC Part 15 (Class B)
CE EMC (Class B)
RCM (Class B)
BSMI
Safety
LVD (EN62368-1)
