Interface ports
2 x 2.5-GbE Ethernet
2 x 2.5-GbE/PoE Ethernet (802.3at, total 30W)
8 x 1-GbE Ethernet
USB 3.0 ports
1
Console port
Yes (RJ-45)
Rack-mountable
Yes
Fanless
-
SPI firewall throughput (Mbps)*2
10,000
VPN throughput (Mbps)*3
2,000
IPS throughput (Mbps)*4
3,500
Anti-Malware throughput (Mbps)*4
2,500
UTM throughput (Anti-malware & IPS, Mbps)*4
Max. TCP concurrent sessions*5
1,000,000
Max. concurrent IPsec VPN tunnels*6
300
Recommended gateway-to-gateway IPsec VPN tunnels
150
Concurrent SSL VPN users
VLAN interface
64
Max. Concurrent devices logins*7
Anti-Malware
IPS
Application Patrol
Web filtering
Reputation Filter
SecuReporter
Sandboxing
Device Insight
Secure WiFi*9
VPN
IKEv2, IPSec, SSL
SSL (HTTPS) inspection
Two-Factor Authentication
Nebula Centralized Management
Power input
19V DC, 4.736A
Max. power consumption (Watt Max.)
68
Heat dissipation (BTU/hr)
211.3
PoE power budget (watt max.)
30
Item
Dimensions (WxDxH)(mm/in.): 300 x 182 x 43.5/11.81 x 7.17 x 1.71
Weight (kg/lb.): 1.64/3.62
Packing
Dimensions (WxDxH)(mm/in.): 350 x 149 x 244/13.78 x 5.87 x 9.61
Weight (kg/lb.): 2.93/6.46
Included accessories
Power adapter & Power cord
RJ-45 - RS-232 cable for console connection
Rack mounting kit
Operating
Temperature: 0°C to 40°C / 32°F to 104°F
Humidity: 10% to 90% (non-condensing)
Storage
Temperature: -30°C to 70°C / -22°F to 158°F
Humidity: 10% to 90%(non-condensing)
MTBF (hr)
40°C/ 346653.298 hr
25°C/ 491775.8384 hr
Acoustic noise
16.86dBA on < 25degC Operating Temperature, 43.76dBA on full FAN speed
EMC
FCC Part 15 (Class A)
CE EMC (Class A)
RCM (Class A)
BSMI
Safety
LVD (EN62368-1)
