WiFi standard
-
10/100/1000 Mbps RJ-45 ports
4 x LAN/DMZ, 1 x WAN
USB 3.0 ports
1
Console port
RJ45
Rack-mountable
Fanless
Yes
SPI firewall throughput (Mbps)*2
350
VPN throughput (Mbps)
90
VPN IMIX Throughput (Mbps)*3
40
IPS throughput (Mbps)*4
Anti-Malware throughput (Mbps)*4
UTM throughput (Anti-malware & IPS, Mbps)*4
Max. TCP concurrent sessions*5
20,000
Recommended gateway-to-gateway IPsec VPN tunnels
5
Max. concurrent IPsec VPN tunnels*6
20
VLAN interface
8
Standard compliance
Wireless frequency
Radio
SSID number
No. of antenna
Antenna gain
Data rate
Security Service
Sandboxing*7
Reputation Filter*7
IPS*7
Application Patrol*7
Email Security*7
Web filtering*7
SecuReporter*7
Collaborative Detection & Response*7
SSL (HTTPS) Inspection
Geo Enforcer
2-Factor Authentication
Device Insight
Security Profile Sync*7
VPN Features
VPN
IKEv2, IPSec, L2TP/IPSec
Microsoft Azure
Amazon VPC
WLAN Management
Default Number of Managed AP
Recommend max. AP in 1 AP Group
Secure WiFi Service*7
Maximum No. of Tunnel-Mode AP
Maximum No. of Managed AP
Management & Connectivity
Nebula Cloud Mode
Nebula Cloud Monitoring Mode
Device HA Pro
Link Aggregation (LAG)
Hotspot Management*7
Ticket printer support*9/ Support Qty (max.)
Concurrent device logins (default/max.)*7*8
64
Power input
12V DC, 2.0 A max.
Max. power consumption (Watt Max.)
12
Heat dissipation (BTU/hr)
40.92
Item
Dimensions (WxDxH)(mm/in.): 216 x 147.3 x 33/8.50 x 5.80 x 1.30
Weight (kg/lb.): 0.88/1.94
Packing
Dimensions (WxDxH)(mm/in.): 276 x 185 x 98/10.87 x 7.28 x 3.86
Weight (kg/lb.): 1.41/3.11
Included accessories
Power adapter
RJ-45 - RS-232 cable for console connection
Operating
Temperature: 0°C to 40°C / 32°F to 104°F
Humidity: 10% to 90% (non-condensing)
Storage
Temperature: -40°C to 70°C/-40°F to 158°F
Humidity: 10% to 90%(non-condensing)
MTBF (hr)
1110,795(at 25?) and 655,130(at 40?)
Acoustic noise
EMC
FCC Part 15 (Class B)
CE EMC (Class B)
RCM
BSMI
Safety
UL
