StarTech 2.5/3.5" SATA USB3.0 SATA dokkoló UASP

The SDOCKU33BV UASP-enabled USB 3.0 docking station makes it easy for you to connect and swap 2.5in or 3.5in SATA III hard drives (HDD) and solid state drives (SSD) through an available USB port. The dock performs up to 70% faster than conventional USB 3.0 when paired with a UASP-enabled host controller to utilize the full potential of your SATA III hard drives.

With support for large capacity SATA I/II/III drives (tested up to 4TB), and 2.5in or 3.5in drives this HDD/SSD docking station is compatible with virtually any SATA drive, and greatly increases the storage/backup capabilities of your computer.

Extend the value of this hard drive docking station further with the addition of our SATA to IDE Hard Drive Adapter (SAT2IDEADP), allowing easy insertion of any 2.5 or 3.5in IDE hard drive into a SATA hard drive dock.

To ensure compatibility with your computer system, the SDOCKU33BV supports all of the leading operating systems, including: Microsoft Windows® (8/7/Vista/XP/Server 2008/Server 2003), Apple® OSX (10.9/10.8/10.7/10.6), Linux, and Google Chrome OS™.

The SDOCKU33BV is backed by a 2-year StarTech.com warranty and free lifetime technical support.

UASP is supported in Windows 8, Mac OSX (10.8 or above), and Linux. In testing, UASP performs with a 70% faster read speed and 40% faster write speed over traditional USB 3.0 at peak performance.

At the same peak in testing UASP also shows an 80% reduction in required processor resources.

Testing results were obtained using an Intel® Ivy Bridge system, a UASP-enabled StarTech.com Enclosure, and a SATA III solid state drive.



Hardware
Chipset ID	ASMedia - ASM1053 - 6G
Compatible Drive Types (Type and Rate)	SATA
Drive Installation	Removable
Drive Size	2.5in & 3.5in
Fan(s)	No
Interface	USB 3.0
Number of Drives	1
Connector(s)
Drive Connectors	1 - SATA Data & Power Combo (7+15 pin) Receptacle
Host Connectors	1 - USB Type-B (9 pin) USB 3.0 Female
Software
Microsoft WHQL Certified	Yes
OS Compatibility	OS independent; No software or drivers required
Indicators
LED Indicators	1 - Power/Activity
Power
Input Voltage	100 ~ 240 AC
Output Voltage	12 DC
Power Source	AC Adapter Included
Environmental
Humidity	20%RH ~ 80%RH
Operating Temperature	5°C to 35°C (41°F to 95°F)
Storage Temperature	-20°C to 50°C (-4°F to 122°F)
Physical Characteristics
Color	Black
Product Height	2 in [52 mm]
Product Length	5.5 in [139 mm]
Product Weight	24.9 oz [704 g]
Product Width	3.6 in [91 mm]
Packaging Information
Shipping (Package) Weight	24.9 oz [704 g]
What's in the Box
Included in Package	1 - USB 3.0 SATA hard drive docking station
	1 - USB 3.0 Cable
	1 - Universal Power Adapter (NA/EU/UK) and AU in Australia
	1 - Instruction Manual
