Zyxel GS1350-6HP CCTV PoE switch 60W

Name: Zyxel GS1350-6HP CCTV PoE switch 60W
Brand: Zyxel
SKU: NET002172
Price: 64500 HUF
Availability: OutOfStock

LAN (1Gb/s): 5 port, SFP: 1db, menedzselhető

Gyártói cikkszám:

GS1350-6HP-EU0101F

Termék ára:

64 500 Ft (bruttó)

darab

Garancia:

60 hónap szakszerviz Garanciális útmutató»

Zyxel GS1350-6HP CCTV PoE switch 60W

HASONLÓ TERMÉKEK

TARTOZÉKOK-KIEGÉSZÍTŐK

ADATOK
CSOMAGOK
LEÍRÁS
LINKEK
HÍREK
VIDEÓ

Fő tulajdonságok
- modell

  GS1350-6HP CCTV
- fő tulajdonság

  switch
- PoE

  igen
Csatlakozók
- LAN (1Gb/s)

  5 port
- SFP

  1db
Egyéb tulajdonságok
- menedzselhető

  igen

Garancia: 5 Év

Models	GS1350-6HP	GS1350-12HP	GS1350-18HP	GS1350-26HP
Model
Product name	5-port GbE Smart Managed PoE Switch with GbE Uplink	8-port GbE Smart Managed PoE Switch with GbE Uplink	16-port GbE Smart Managed PoE Switch with GbE Uplink	24-port GbE Smart Managed PoE Switch with GbE Uplink
Switch class	Smart Managed	Smart Managed	Smart Managed	Smart Managed
Port Density
Total port count	6	12	18	26
100/1000 Mbps	5	10	16	24
Gigabit SFP	1	2	-	-
Gigabit combo (RJ-45/SFP)	-	-	2	2
Configurable extended range ports	5	8	16	16
PoE
PoE ports	5	8	16	24
Total PoE budget (watt)	60	130	250	375
PoE Standard	802.3af/at 802.3bt (port 1-2)	802.3af/at	802.3af/at	802.3af/at
Performance
Switching capacity (Gbps)	12	24	36	52
Forwarding rate (Mpps)	8.9	17.8	26.7	38.7
Packet buffer (byte)	525 K	525 K	525 K	525 K
MAC address table	8 K	8 K	8 K	8 K
Power
Input	52 V - 57 V DC	100 - 240 V AC, 50/60 Hz	100 - 240 V AC, 50/60 Hz	100 - 240 V AC, 50/60 Hz
Max. power consumption (watt)	72	160.3	300.9	448.9
Physical Specifications
Dimensions (WxDxH)(mm/in.)	193 x 84 x 26 / 7.6 x 3.31 x1.02	267 x 162 x 44 / 10.51x 6.38 x1.73	330 x 230 x 44 / 12.99 x 9.06 x1.73	441 x 270 x 44 / 17.36 x10.63 x 1.73
Weight (kg/lb.)	0.41/0.9	1.63/3.59	2.42/5.34	3.58/7.89
Included accessories	Power adapter Wall-mount kit	Power cord Rack mounting kit	Power cord Rack mounting kit	Power cord Rack mounting kit
ESD/Surge Protections
Ethernet port surge protection	4 KV	4 KV	4 KV	4 KV
Power supply surge protection: Line-GND	4 KV	4 KV	4 KV	4 KV
Power supply surge protection: Line-Line	2 KV	2 KV	2 KV	2 KV
Ethernet port ESD protection (air/contact)	15 KV/8 KV	15 KV/8 KV	15 KV/8 KV	15 KV/8 KV
Environmental Specifications
Operating	Temperature -20°C to 50°C/-4°F to 122°F Humidity 5% to 95% (non-condensing)	Temperature -20°C to 50°C/-4°F to 122°F Humidity 5% to 95% (non-condensing)	Temperature -20°C to 50°C/-4°F to 122°F Humidity 5% to 95% (non-condensing)	Temperature -20°C to 50°C/-4°F to 122°F Humidity 5% to 95% (non-condensing)
Storage	Temperature -40°C to 70°C/-40°F to 158°F Humidity 5% to 95% (non-condensing)	Temperature -40°C to 70°C/-40°F to 158°F Humidity 5% to 95% (non-condensing)	Temperature -40°C to 70°C/-40°F to 158°F Humidity 5% to 95% (non-condensing)	Temperature -40°C to 70°C/-40°F to 158°F Humidity 5% to 95% (non-condensing)
MTBF (hr)	2,021,885.87	1,065,025.45	1,699,692.18	888,495
Heat dissipation (BTU/hr)	245.52	546.62	1,026.07	1,530.75
Acoustic noise @ 25°C (dBA)	0 (Fanless)	27.3	39	40.1
