Lenovo ThinkPad Mini Dock USB-C dokkoló szürke

Maximize Your Productivity with a Thunderbolt 3 Dock.; Powerful, versatile and incredibly fast!; The Intel® Thunderbolt™ Chipset powered Thunderbolt Dock Gen 2 has been invented to boost productivity with extended compatibility on both USB-C and Thunderbolt enabled laptops.; Expand your horizons with multiple 4K displays, and transfer files at record speed.It’s everything you need to enhance your creativity and efficiency today.;

• Expand compatibility on USB-C and Thunderbolt systems
• Dual UHD Displays provide the best video expereince
• Enhanced performance with professional video solution and exclusive network manageability.
• Depending on many factors such as the processing capability of the host and peripheral devices, file attributes, and other factors related to system configuration and operating environments, the actual data transfer rate will be slower than 5 Gbit/s on USB 3.1 Gen 1 (USB 3.0) connectors, slower than 10 Gbit/s on USB 3.1 Gen 2 connectors, and slower than 20Gbit/s on USB 3.2 connectors.

Tech Specs

Warranty Period	3 years
Warranty Type	CRU
Power Delivery	Yes
Output Power	90W
Power Button	Yes
Power Plug	slim tip Black
Agency Approvals	CE-EMC, TUV Mark,KCC,Serbia Kvalitet, CU EAC
Supported OS	Win10
Hardware Requirements	ThinkPad
Driver Needed	Yes, ready at Preload
Length	220mm
Depth	80mm
Height	30mm
Product Weight	525g
Shipment Group	135W adapter, 1x power cord, standard Thunderbolt cable,warranty and setup poster
Package Type	brown box
Packed Dimensions (L x D x H)	270x164x75mm
Packed Weight	1395g
Minimum Operating Temperature	0 celsius
Maximum Operating Temperature	40 celsius
Minimum Relative Humidity (%)	5%
Maximum Relative Humidity (%)	95%
UPC	192158239569
EAN	0192158239569
JAN	4589701830537

Compatibility

Operating System

OS Independent

Compatible Machines

Description	ID	Footnote
IdeaPad S700 Series-Lenovo IdeaPad S730-13IML	81U5
IdeaPad S900 Series-Lenovo IdeaPad S940-14IWL	81R0
ThinkPad E Series-E490	20N8	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20N9	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
ThinkPad E Series-E490s	20NG
ThinkPad E Series-E590	20NB	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20NC	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
ThinkPad E14 Series-E14-IML	20RA
	20RB
ThinkPad E15 Series-E15-IML	20RD
	20RE
ThinkPad L Series-L390	20NR	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20NS	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20NT	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20NU	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
ThinkPad L Series-L480	20LS
	20LT
ThinkPad L Series-L490	20Q5	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20Q6	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
ThinkPad L Series-L580	20LW	30. ThinkStation models offer two PCI-e x16 graphic slots allowing two graphic cards to be installed.
	20LX	30. ThinkStation models offer two PCI-e x16 graphic slots allowing two graphic cards to be installed.
ThinkPad L Series-L590	20Q7	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20Q8	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
ThinkPad L13 Series-L13 Clam 2019	20R3	341. PXE boot supported. Wake On LAN from Sleep, Hibernation, or Power-Off mode.MAC address pass through. Make sure dock with FW 1.0.3.08281 or later version, Dock FW website:https://support.lenovo.com/us/zh/solutions/acc500106
	20R4	341. PXE boot supported. Wake On LAN from Sleep, Hibernation, or Power-Off mode.MAC address pass through. Make sure dock with FW 1.0.3.08281 or later version, Dock FW website:https://support.lenovo.com/us/zh/solutions/acc500106
ThinkPad L13 Series-L13 Yoga 2019	20R5	341. PXE boot supported. Wake On LAN from Sleep, Hibernation, or Power-Off mode.MAC address pass through. Make sure dock with FW 1.0.3.08281 or later version, Dock FW website:https://support.lenovo.com/us/zh/solutions/acc500106
	20R6	341. PXE boot supported. Wake On LAN from Sleep, Hibernation, or Power-Off mode.MAC address pass through. Make sure dock with FW 1.0.3.08281 or later version, Dock FW website:https://support.lenovo.com/us/zh/solutions/acc500106
ThinkPad P Series-P43s	20RH	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20RJ	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
ThinkPad P Series-P51s	20HB
	20HC
	20JY
	20K0
ThinkPad P Series-P52s	20LB
	20LC
ThinkPad P Series-P53s	20N6	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20N7	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
ThinkPad T Series-T470	20HD
	20HE
	20JM
	20JN
ThinkPad T Series-T470s	20HF	30. ThinkStation models offer two PCI-e x16 graphic slots allowing two graphic cards to be installed.
	20HG	30. ThinkStation models offer two PCI-e x16 graphic slots allowing two graphic cards to be installed.
	20JS	30. ThinkStation models offer two PCI-e x16 graphic slots allowing two graphic cards to be installed.
	20JT	30. ThinkStation models offer two PCI-e x16 graphic slots allowing two graphic cards to be installed.
ThinkPad T Series-T480	20L5
	20L6
ThinkPad T Series-T480s	20L7
	20L8
ThinkPad T Series-T490	20N2	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20N3	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20Q9	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20QH	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
ThinkPad T Series-T490s	20NX	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20NY	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
ThinkPad T Series-T495	20NJ	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20NK	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
ThinkPad T Series-T495s	20QJ	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20QK	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
ThinkPad T Series-T570	20H9
	20HA
	20JW
	20JX
ThinkPad T Series-T580	20L9
	20LA
ThinkPad T Series-T590	20N4	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20N5	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
ThinkPad X Series-ThinkPad X270	20HM	341. PXE boot supported. Wake On LAN from Sleep, Hibernation, or Power-Off mode.MAC address pass through. Make sure dock with FW 1.0.3.08281 or later version, Dock FW website:https://support.lenovo.com/us/zh/solutions/acc500106
	20HN	341. PXE boot supported. Wake On LAN from Sleep, Hibernation, or Power-Off mode.MAC address pass through. Make sure dock with FW 1.0.3.08281 or later version, Dock FW website:https://support.lenovo.com/us/zh/solutions/acc500106
ThinkPad X1 Series-ThinkPad Yoga 370	20JH	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20JJ	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
ThinkPad X1 Series-X1 Carbon 5th Generation	20HQ	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20HR	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20K3	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20K4	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
ThinkPad X1 Series-X1 Carbon 7th Generation	20QD	50. For 2nd HDD support in the ThinkPad Ultrabase Series 3 (0A33932), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X220, X230 systems.
	20QE	50. For 2nd HDD support in the ThinkPad Ultrabase Series 3 (0A33932), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X220, X230 systems.
	20R1
	20R2
ThinkPad X1 Series-X1 Yoga 2nd Generation	20JD
	20JE
	20JF
	20JG
ThinkPad X1 Series-X1 Yoga 3rd Generation	20LD	50. For 2nd HDD support in the ThinkPad Ultrabase Series 3 (0A33932), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X220, X230 systems.
	20LE	50. For 2nd HDD support in the ThinkPad Ultrabase Series 3 (0A33932), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X220, X230 systems.
	20LF	50. For 2nd HDD support in the ThinkPad Ultrabase Series 3 (0A33932), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X220, X230 systems.
	20LG	50. For 2nd HDD support in the ThinkPad Ultrabase Series 3 (0A33932), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X220, X230 systems.
ThinkPad X1 Series-X1 Yoga 4th Generation	20QF	50. For 2nd HDD support in the ThinkPad Ultrabase Series 3 (0A33932), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X220, X230 systems.
	20QG	50. For 2nd HDD support in the ThinkPad Ultrabase Series 3 (0A33932), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X220, X230 systems.
	20SA
	20SB
ThinkPad X1 Series-X270	20K5	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20K6	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
ThinkPad X1 Series-X280	20KE
	20KF
ThinkPad X1 Series-X380 Yoga	20LH	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20LJ	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
ThinkPad X1 Series-X390	20Q0	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20Q1	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20SC
	20SD
ThinkPad X1 Series-X390 Yoga	20NN	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20NQ	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
ThinkPad X1 Series-X395	20NL	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
	20NM	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
ThinkPad X1 Tablet-ThinkPad X1 Tablet Gen 3	20KJ	50. For 2nd HDD support in the ThinkPad Ultrabase Series 3 (0A33932), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X220, X230 systems.
	20KK	50. For 2nd HDD support in the ThinkPad Ultrabase Series 3 (0A33932), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X220, X230 systems.
ThinkPad s Series-S1 4th Gen	20LK	28. For 2nd HDD support in the ThinkPad X200 UltraBase (43R8781), the ThinkPad Serial Hard Drive 9.5mm Bay Adapter III (43N3412) is required. These drives are supported as the primary hard drive upgrade in the X200 systems.
Thinkbook Series-ThinkBook 13s-IML	20RR
Thinkbook Series-ThinkBook 14s-IML	20RS
Yoga C900 Series-Lenovo Yoga C940-14IIL	81Q9
Yoga S700 Series-Lenovo Yoga S730-13IML	81U4
Yoga S900 Series-Lenovo Yoga S940-14IWL	81Q7
