Compatibility
Intel LGA1700/1200/2066/2011/1151/1150/1155/1156
AMD AM5/AM4
TDP
220W
Overall Dimension
120×110×135mm (L×W×H)
Heatsink Material
7×?6mm Heatpipe+Copper Base+Aluminum Fin
Weight
760g (Heatsink+Fan)
Fan Dimension
120×120×25mm
Fan Speed
700±200~1800±10%RPM(PWM)
Max. Air Flow
76.16CFM
Max. Static Pressure
2.16mmH2O
Noise
15.2-35.2dB(A)
Rated Voltage
12VDC (4pin PWM)
Operating Voltage
10.8~13.2VDC
Started Voltage
7VDC
Rated Current
0.2A
Power Input
2.4W
Bearing Type
Hydraulic Bearing
Connector
4Pin PWM
