Printer Type
Laser
Print Method
Electrophotographic Laser Printer
Memory Capacity
Standard
1 GB
2 GB
Machine display
(DCP-L5510DN/DCP-L5660DN/MFC-L5710DN/MFC-L5710DW)
3.5 in. TFT Colour touchscreen LCD 70.08 x 52.56 mm *1
(MFC-L5915DW/MFC-L6720DW)
5.0 in. TFT Colour touchscreen LCD 108.00 x 64.8 mm *1
(MFC-L6915DW)
7.0 in. TFT Colour touchscreen LCD 153.84 x 85.63 mm *1
Power Source
220 V to 240 V AC 50/60 Hz
Power Consumption
(Average)
Peak
Approximately 1,280 W
Printing *2
Approximately 670 W at 25°C
Approximately 710 W at 25°C
Printing
(Quiet Mode) *2
Approximately 430 W at 25°C
Copying *2
Approximately 680 W at 25°C
Copying
Ready *2
Approximately 31 W at 25°C
Sleep *2
Approximately 5.9 W
Approximately 6.0 W
Approximately 6.7 W
Deep Sleep *2
Approximately 0.6 W
Approximately 0.8 W
Approximately 0.7 W
Power Off *3 *4
Approximately 0.05 W
Dimensions
(Typical outline view)
Unit: mm
(DCP-L5510DN/MFC-L5710DN/MFC-L5710DW)
* : 417
** : 448
*** : 461
(DCP-L5660DN)
* : 495
** : 486
*** : 460
(MFC-L5915DW)
*** : 473
(MFC-L6720DW)
** : 518
*** : 495
Weight (with supplies)
(For Australia and New Zealand)
(MFC-L5710DW)
16.4 kg
17.4 kg
18.9 kg
19.7 kg
(For other countries)
(DCP-L5510DN/MFC-L5710DN)
16.8 kg
16.9 kg
17.1 kg
17.8 kg
20.4 kg
Noise Level
Sound Pressure *5
LpAm = 54.0 dB (A)
(Quiet Mode)
LpAm = 50 dB (A)
Ready
LpAm = Up to 35.0 dB (A)
Sound Power
Printing *5
(DCP-L5510DN/DCP-L5660DN/MFC-L5710DN/MFC-L5710DW/MFC-L5915DW)
LWAc = 7.02 B (A)
(MFC-L6720DW/MFC-L6915DW)
LWAc = 7.06 B (A)
LWAc = 6.54 B (A)
LWAc = Up to 4.9 B (A)
Temperature
Operating
From 10°C to 32.5°C
Storage
From 0°C to 40°C
Humidity
20% to 80% (without condensation)
35% to 85% (without condensation)
Automatic Document Feeder (ADF)
Up to 50 sheets
(DCP-L5660DN/MFC-L5915DW/MFC-L6720DW)
Up to 70 sheets
Up to 80 sheets
For best results we recommend:
Temperature: 20°C to 30°C
Humidity: 50% to 70%
Paper: 80 g/m2
*1
Measured diagonally.
*2
Measured when the machine is connected using the same network connection as the ENERGY STAR Ver. 3.1 test method.
*3
Measured according to IEC 62301 Edition 2.0.
*4
Power consumption varies slightly depending on the usage environment.
*5
Measured in accordance with the method described in ISO 7779.
Document Size
ADF Width
105 mm to 215.9 mm
ADF Length
147.3 mm to 355.6 mm
Scanner Glass Width
Maximum 216 mm
Scanner Glass Length
Maximum 300 mm
(DCP-L5660DN/MFC-L5915DW/MFC-L6720DW/MFC-L6915DW)
Maximum 355.6 mm
Paper Input
Paper Tray
(Standard)
Paper Type
Plain Paper, Letterhead, Coloured Paper, Thin Paper, Recycled Paper, Thick Paper
Paper Size
A4, Letter, B5 (JIS), A5, A5 (Long Edge), A6, Executive, Legal, Mexico Legal, India Legal, Folio, 16K (195x270 mm), A4 Short (270mm Paper)
Paper Weight
60 to 163 g/m2 *1
Maximum Paper Capacity
Up to 250 sheets of 80 g/m2 Plain Paper
Up to 520 sheets of 80 g/m2 Plain Paper
Multi-Purpose Tray (MP tray)
Plain Paper, Letterhead, Coloured Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Bond, Label, Envelope, Env.Thin, Env.Thick
Width:
69.8 to 215.9 mm
Length:
127 to 355.6 mm
Envelope:
COM-10, DL, C5, Monarch
60 to 230 g/m2 *1
Up to 100 Sheets of 80 g/m2 Plain Paper
Envelope: Up to 11 mm thick
Paper Tray 2, 3
(Optional) *2
A4, Letter, B5 (JIS), A5, Executive, Legal, Mexico Legal, India Legal, Folio, 16K (195x270 mm), A4 Short (270mm Paper)
60 to 120 g/m2 *1
LT-5505
LT-6505
Paper Output *3
Face Down Output Tray
(DCP-L5510DN/DCP-L5660DN/MFC-L5710DN/MFC-L5710DW/MFC-L5915DW/MFC-L6720DW)
Up to 150 sheets of 80 g/m2 Plain Paper (face-down delivery to the face-down output paper tray)
Up to 250 Sheets of 80 g/m2 Plain Paper (face down delivery to the face down output paper tray)
Face Up Output Tray
One sheet (face up delivery to the face up output tray)
Up to 10 sheets (face up delivery to the face up output tray)
2-sided
Automatic 2-sided Printing
Plain Paper, Letterhead, Coloured Paper, Thin Paper, Recycled Paper
For Australia, Korea, and New Zealand
A4
For other countries
Select the paper size you want to use by sliding the 2-sided lever:
Letter, Legal, Mexico Legal, India Legal, Folio
60 to 105 g/m2
For paper of 105 g/m2 and above, open the back cover to use the face up output tray.
Maximum number of Lower Trays: Up to two Lower Trays in any combination.
For labels, we recommend removing the printed sheets from the output paper tray immediately after they exit the machine to avoid the possibility of smudging.
This feature is available for MFC models.
Compatibility
ITU-T Super Group 3
Coding System
MH / MR / MMR / JBIG
Modem Speed
33,600 bps (with Automatic Fallback)
2-sided Print Receiving
Yes
Automatic 2-sided Sending
(MFC-L5710DN/MFC-L5710DW/MFC-L5915DW/MFC-L6720DW/MFC-L6915DW)
Yes (from the ADF)
Scanning Width
Maximum 208 mm
Printing Width
Maximum 207.4 mm
Greyscale
8 bit / 256 levels
Resolution
Horizontal
203 dpi
Vertical
Standard: 98 dpi
Fine: 196 dpi
Super fine: 392 dpi
Photo: 196 dpi
Address Book *1
300 Locations
Groups *1
Up to 20
Broadcasting
350 Locations
Automatic Redial
3 times at 5-minute intervals
Memory Transmission
Up to 500 pages *2
Out of Paper Reception
Available for DCP and MFC models
‘Pages’ refers to the ‘ITU-T TestChart Document No.1’ (a typical business letter, Standard resolution, JBIG code).
Copy Width
Maximum 210 mm
Automatic 2-sided Copy
(DCP-L5660DN/MFC-L5710DN/MFC-L5710DW/MFC-L5915DW/MFC-L6720DW/MFC-L6915DW)
Sort Copy
Stack Copy
Up to 999 pages
Enlarge/Reduce
25 to 400% (in increments of 1%)
Maximum 1200 x 600 dpi
First Copy Out Time *1
Less than 8.7 seconds at 23°C
From Ready Mode and standard tray.
Colour / Black
Yes / Yes
TWAIN Compliant
(Windows 10 / Windows 11)
WIA Compliant
Colour Depth
48 bit colour Processing (Input)
24 bit colour Processing (Output)
Grey Scale
16 bit colour Processing (Input)
8 bit colour Processing (Output)
Resolution *1
Up to 19200 x 19200 dpi (interpolated)
Up to 1200 x 1200 dpi (from Scanner Glass)
Up to 600 x 600 dpi (from the ADF)
Automatic 2-sided Scanning
Maximum 1200 × 1200 dpi scanning with the WIA driver in Windows 10 and Windows 11 (resolution up to 19200 × 19200 dpi can be selected by using the scanner utility)
Automatic 2-sided Print
Emulation
PCL6, BR-Script3, IBM Proprinter XL, Epson FX-850, PDF version1.7, XPS version 1.0
Up to 1200 x 1200 dpi
Print Speed *1
1-sided Print *2 *3
Up to 50 pages/minute (Letter size)
Up to 48 pages/minute (A4 size)
(MFC-L5915DW/MFC-L6720DW/MFC-L6915DW)
Up to 52 pages/minute (Letter size)
Up to 50 pages/minute (A4 size)
2-sided Print
Up to 24 sides/minute (Up to 12 sheets/minute) (Letter size)
Up to 24 sides/minute (Up to 12 sheets/minute) (A4 size)
First Print Time *4 *5 *6
Less than 6.7 seconds at 23°C
The print speed may be slower when the machine is connected by wireless LAN.
The print speeds of "1-sided Print" were measured in accordance with ISO/IEC 24734.
This speed is based on 1-sided printing. If your model’s default print setting is "2-sided", change to "1-sided" for these results.
Printing from Ready mode and standard tray.
Length of time from when the machine is started until paper output is complete (except when the machine is turned on or when an error is fixed)
*6
This applies when printing on A4- or Letter-size paper from the standard tray. It could be longer however, depending on the paper size and the amount of print data.
USB
Type: USB Type-B receptacle
Version: USB 2.0 High-Speed *1 *2
Use a USB 2.0 interface cable that is no more than 2 metres long.
Type: USB Type-A receptacle (Front) *3
Type: USB Type-A receptacle (Rear) *3
Version: USB 2.0 High-Speed
Connect a USB flash drive for USB Storage Print.
LAN
10Base-T/100Base-TX/1000Base-T *4
Wireless LAN
(MFC-L5710DW/MFC-L5915DW/MFC-L6720DW/MFC-L6915DW)
IEEE 802.11a/b/g/n (Infrastructure Mode)
IEEE 802.11a/g/n (Wi-Fi Direct®)
NFC *5
Your machine has a USB 2.0 Hi-Speed interface. The machine can also be connected to a computer that has a USB 1.1 interface.
Third party USB hub devices are not supported.
USB host port
Use a Category 5e (or greater) network cable.
When you connect an external IC card reader, use a HID class driver supported device.
PDF version1.7, JPEG, Exif+JPEG, PRN (created by the machine's own printer driver), TIFF (scanned by Brother models), XPS version 1.0
Interface
USB direct interface: Front x1, Rear x1 (MFC-L6915DW)
Supported protocols and security features may differ depending the models.
10Base-T/100Base-TX/1000Base-T
ARP, RARP, BOOTP, DHCP, APIPA (Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, POP3, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print/Scan), SNTP Client, LDAP, IMAP4, Syslog
NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, POP3, SMTP Client, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMPv6, SNTP Client, LDAP, Web Services (Print/Scan), IMAP4, Syslog
APOP, SMTP-AUTH, SSL/TLS (IPP, HTTP, SMTP, FTP, POP3, IMAP4, LDAP), SNMP v3 802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS), Kerberos, IPsec
APOP, SMTP-AUTH, SSL/TLS (IPP, HTTP, SMTP, FTP, POP3, IMAP4, LDAP), SNMP v3, 802.1x (EAP-FAST, PEAP, EAP-TLS, EAP-TTLS), Kerberos, IPsec
WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA3-SAE (AES) (Wi-Fi Direct supports WPA2-PSK (AES) only)
Wi-Fi Certification Mark License (WPA3™ - Enterprise, Personal), Wi-Fi Protected Setup™ (WPS) Identifier Mark License, Wi-Fi CERTIFIED™ Wi-Fi Direct
Supported Operating Systems And Software Functions
For the latest supported OS, go to your model's Supported OS page at support.brother.com/os.
Computer Platform & Operating System Version
Processor
Hard Disk Space to Install *1
USB *2
(Ethernet)
Wireless
802.11a/b/g/n
For Drivers
For Applications
(including Drivers)
Windows Operating System
Windows 10 Home / 10 Pro / 10 Education / 10 Enterprise *3 *4
PC Fax *5
Scanning
32 bit (x86) or 64 bit (x64) processor
80 MB
1.8 GB
Windows 11 Home / 11 Pro / 11 Education / 11 Enterprise *3 *4
64 bit (x64) processor
Windows Server 2012
Windows Server 2012 R2
Windows Server 2016
Windows Server 2019
Windows Server 2022
Mac Operating System *6
macOS v11
PC-Fax (Send) *5 *7
64 bit processor
N/A
500 MB
macOS v12
macOS v13
Chrome OS
An Internet connection is required to install the software if the installation disc is not supplied.
Third party USB ports are not supported.
For WIA, 1200x1200 resolution. Brother Scanner Utility enables resolutions up to 19200 x 19200 dpi.
PaperPort™ 14SE supports Windows 10 and Windows 11.
PC-Fax supports black and white only.
macOS Disclaimer
AirPrint capable: Printing or scanning via Mac requires using AirPrint. Mac drivers are not provided.
*7
AirPrint only.
