Dimension
163.5 x 116.8 x 28.5 mm 0.54 L
Motherboard Size
154 x 110 mm
CPU
Intel® Processor N100 2.9G~3.4G Turbo, 4C/4T Core, 6MB L3 Cache
Memory
1 x SO-DIMM DDR4 slot 3200MHz Max. 32GB
LAN
2.5GbE LAN (Realtek RTL8125)
Wifi Card
Intel AX101 Wi-Fi 6 ; 802.11ax ; 2.4 & 5 GHz
Graphics
Intel® UHD Graphics 750
Audio
Realtek ALC897
HDMI Resolution (Max.)
HDMI2.1 Support 4K@60P HDR10
Mini DP Resolution (Max.)
DP 1.4 support 4K@60P HBR2
Storage
1 x M.2 2280 slots for SSD (PCI-e x2 or SATA) 1 x M.2 2280 slots for SSD (PCI-e x2)
Expansion Slots
1 x M.2 2280 slots for SSD (PCI-e x2 or SATA) 1 x M.2 2280 slots for SSD (PCI-e x2) 1 x M.2 2230 slot (PCI-e x1 ; A-E key slot occupied by the Wi-Fi + Bluetooth card)
Front I/O
1 x Power Button 1 x USB3.2 Gen2 Type-A 1 x USB3.2 Gen2 Type-C 1 x Headphone / Microphone
Rear I/O
2 x HDMI 2.1 1 x 2.5 GbE RJ45 3 x USB 2.0 Type-A 1 x USB 3.2 Gen2 Type-A 1 x DC-In 1 x DP 1.4 1 x Kensington lock slot
Power Supply
Input: AC 100-240V Output: DC 19V/3.42A, 65W
VESA
VESA support Supports 75 x 75 and 100 x 100 mm *VESA Bracket to be purchased seperately.
Support OS
Win11 64bit
Environment
System Environment Operating Temperature: 0°C to +35°C System Storage Temperature: -20°C to +60°C
