Standard
IEEE802.11 ax/ac/n/g/b/a
MIMO
MU-MIMO
Wireless speed
2.4GHz: 575 Mbps
5GHz: 4800 Mbps
Frequency band
2.4GHz:
USA (FCC): 2.412 to 2.462GHz
Europe (ETSI): 2.412 to 2.472GHz
5GHz:
USA (FCC): 5.15 to 5.35GHz; 5.470 to 5.850GHz
European (ETSI): 5.15 to 5.35GHz; 5.470 to 5.725GHz
Bandwidth
20-, 40- ,80-, and 160-MHz
Conducted typical transmit output power*1
US (2.4GHz/5GHz):
26/28 dBm
EU (2.4GHz/5GHz):
19/26 dBm
Antenna type
Internal Antenna
Antenna gain
1.49dBi, 2X2:2SS
2.78dBi, 4X4:4SS
Minimum receive sensitivity
Min. Rx sensitivity up to -99 dBm
Band steering
Yes
WDS/Smart Mesh*2
Wireless bridge
Fast roaming
Pre-authentication, PMK caching and 802.11r/k/v
DCS
Load balancing
Advanced cellular coexistence
Encryption
WEP
WPA
WPA2
WPA3
Authentication
IEEE 802.1X/ RADIUS authentication
Access management
L2-isolation
MAC filtering
Rogue AP detection
IPv6
VLANs
WMM
U-APSD
Operating mode
Nebula Cloud managed
Standalone
ZON Utility
Discovery of Zyxel switches, APs and gateways
Centralized and batch configurations:
IP configuration
IP renew
Device reboot
Device locating
Web GUI access
Firmware upgrade
Password configuration
Web UI/CLI
SNMP
Item
Dimensions (WxDxH)(mm/in.) 250 x 160 x 47/9.84 x 6.30 x 1.85
Weight (g/lb.) 815/1.80
Packing
Dimensions (WxDxH)(mm/in.) 279.5 x 180.5 x 66/11.00 x 7.11 x 2.60
Weight (g/lb.) 1039/2.29
Included accessories
Mount plate
Mounting screws
MTBF (hr)
691,722
Ethernet port
2 x 1/2.5Gbps LAN
Power
PoE (802.3at): power draw 21.5W
DC input : USB PD15 VDC2A (Type C)
PoE modes
IEEE 802.3af: No Wireless
IEEE 802.3at: Unrestricted
IEEE 802.3bt: Unrestricted
Operating
Temperature 0°C to 50°C / 32°F to 122°F
Humidity 10% to 95% (non-condensing)
Storage
Temperature -40°C to 70°C / -40°F to 158°F
Humidity 10% to 90% (non-condensing)
Radio
FCC Part 15C
FCC Part 15E
FCC Part 2.1091
ETSI EN 300 328
EN 301 893
EN 50385
EN 50665
EN IEC 62311
LP0002
EMC
FCC Part 15B
EN 301 489-1
EN 301 489-17
EN55032
EN55035
EN61000-3-2/-3
EN60601-1-2
BSMI CNS15936
Safety
EN 62368-1
IEC 62368-1
BSMI CNS15598-1
