Panel Size (inch)
34" OLED
Panel Type
OLED
Display Viewing Area (HxV)
800.06 x 337.06 mm
Color Saturation
99% DCI-P3
Resolution
3440 x 1440 (WQHD)
Display Surface
Anti-Reflection
Pixel Pitch
0.2315(H) x 0.2315(V) mm
Brightness
250 cd/m² (Typ, SDR APL 100%); 1000 cd/m² (Typ, HDR APL 3%)
Contrast Ratio (Typ.)
1.5M:1
Viewing Angle
178°(H)/178°(V)
Display Colors
10bit (1.07B)
Refresh Rate (Max)
240Hz
Response Time
0.03ms GTG
HDR Support
VESA DisplayHDR True Black 400
VESA Certified ClearMR
ClearMR 13000
Flicker-free
Yes
Connectivity
2 x HDMI 2.1 1 x Displayport 1.4 1 x USB Type-C (Alternate Mode; Upstream port; Power Delivery up to 18W) 2 x USB 3.2 Downstream ports 1 x USB 3.2 Upstream port 1 x Earphone Jack 1 x Microphone Jack
Earphone Jack
Speaker
3W x 2
Unique Features
Tactical Switch OSD Sidekick * Black Equalizer 2.0 Dashboard Crosshair Timer Counter Eagle Eye PiP/PbP Auto-Update KVM 6 axis Color Control Apply Picture Mode HDMI-CEC
Power Type
Power Board Build-in
Power Consumption
48W **
Power Saving Mode
<0.5W
Power Off Mode
<0.3W
Voltage
AC 100-240V ~ 50/60Hz
Tilt(angle)
-5°~+20°
Swivel(angle)
±30°
Height Adjustment (mm)
130 mm
VESA Wall Mounting(mm)
100*100 mm
Kensington lock
Phys. Dimension with Stand(WxHxD)
811.7 x 595.3 x 244.3 mm
Phys. Dimension w/o stand (WxHxD)
811.7 x 361.2 x 105.8 mm
Box Dimension (WxHxD)
990*527*238 mm
Net Weight with stand (Esti.)
9.86 kg
Net Weight without stand (Esti.)
6.68 kg
Gross Weight (Esti.)
12.5 kg
Accessories
Power cable/HDMI 2.1 cable/DP cable/USB cable/QSG/Warranty card
Note
*To enable OSD Sidekick (integrated in GCC), it requires connection between PC and monitor with HDMI/DP cable. **The test condition follows CEC standards.
