A professional colour laser printer, the MFC-L8690CDW provides great print speeds, combined with comprehensive mobile and cloud connectivity options, making integration into your office seamless.
Printer Type
Laser
Print Method
Electrophotographic Laser Printer
Memory Capacity
Standard
(DCP-L8410CDW/MFC-L8690CDW/MFC-L8900CDW)
512 MB
(MFC-L9570CDW)
1 GB
(DCP-L8410CDW/MFC-L8690CDW)
3.7 in. (93.4 mm) TFT Colour Touchscreen LCD *1
(MFC-L8900CDW)
5.0 in. (125.9 mm) TFT Colour Touchscreen LCD *1
7.0 in. (176.1 mm) TFT Colour Touchscreen LCD *1
Power Source
220 to 240 V AC 50/60 Hz
Power Consumption
(Average)
Peak
Approximately 1230 W
Printing *2
Approximately 580 W at 25 °C
Printing
(Quiet Mode) *2
Approximately 340 W at 25 °C
Copying *2
Approximately 550 W at 25 °C
Copying
Approximately 350 W at 25 °C
Ready *2
Approximately 70 W at 25 °C
Sleep *2
Approximately 10 W
Deep Sleep *2
(DCP-L8410CDW)
Approximately 1.3 W
(MFC-L8690CDW)
Approximately 1.4 W
(MFC-L8900CDW/MFC-L9570CDW)
Approximately 1.7 W
Power Off *2 *3 *4
Approximately 0.03 W
Dimensions
(Typical outline view)
Unit: mm
* : 435
** : 539
*** : 526
* : 495
** : 549
Weights (with supplies)
27.6 kg
27.9 kg
28.7 kg
29.7 kg
Noise Level
Sound Pressure
LpAm = 49 dB (A)
(Quiet Mode)
LpAm = 44 dB (A)
Ready
LpAm = Inaudible
Sound Power
Copying *5 *6
Monochrome
(Excluding Belgium)
LWAd = 6.40 B (A)
(For Belgium)
LWAd = 6.35 B (A)
Colour
LWAd = 6.41 B (A)
LWAd = 6.36 B (A)
LWAd = 6.00 B (A)
Ready *5 *6
LWAd = Inaudible
Temperature
Operating
10 to 32 °C
Storage
0 to 40 °C
Humidity
20 to 80% (without condensation)
10 to 90% (without condensation)
ADF (automatic document feeder)
Up to 50 sheets
Up to 70 sheets
Up to 80 sheets
For best results we recommend:
Temperature: 20 to 30 °C
Humidity: 50 to 70%
Paper: 80 g/m2
Laser Notice
Click here for details.
Document Size
ADF Width
105 to 215.9 mm
ADF Length
147.3 to 355.6 mm
Scanner Glass Width
Maximum 215.9 mm
Scanner Glass Length
Maximum 300 mm
Maximum 355.6 mm
Paper Input
Paper Tray
(Standard)
Paper Type
Plain Paper, Letterhead, Coloured Paper, Thin Paper, Recycled Paper
Paper Size
A4, Letter, A5, A5(Long Edge), A6, Executive, Legal, Folio, Mexico Legal
Paper Weight
60 to 105 g/m2
Maximum Paper Capacity
Up to 250 sheets of 80 g/m2 Plain Paper
Multi-Purpose Tray (MP tray)
Plain Paper, Letterhead, Coloured Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Bond, Label, Envelope, Env. Thin, Env.Thick, Glossy Paper
Width:
76.2 to 215.9 mm
Length:
127 to 355.6 mm
Envelope:
COM-10, DL, C5, Monarch
60 to 163 g/m2
Up to 50 sheets of 80 g/m2 Plain Paper
Envelope: 10 envelopes up to 10 mm thick
Paper Tray 2, 3, 4
(Optional) *1 *2
A4, Letter, A5, Executive, Legal, Folio, Mexico Legal
LT-330CL
LT-340CL *3
Up to 500 sheets of 80 g/m2 Plain Paper
Paper Output *4
Face Down Output Tray
Up to 150 Sheets of 80 g/m2 Plain Paper (face down delivery to the face down output paper tray)
Face Up Output Tray
One sheet (face up delivery to the face up output tray)
2-sided
Automatic 2-sided Printing
A4
This feature is available for MFC models.
Compatibility
ITU-T Super Group 3
Coding System
MH / MR / MMR / JBIG
Modem Speed
33,600 bps (with Automatic Fallback)
2-sided Print Receiving
Yes
Automatic 2-sided Sending
(MFC-L8690CDW/MFC-L8900CDW/MFC-L9570CDW)
Yes (from ADF)
Scanning Width
Maximum 208 mm
Printing Width
Greyscale
8 bit / 256 levels
Resolution
203 dpi
Standard: 98 dpi
Fine: 196 dpi
Super fine: 392 dpi
Photo: 196 dpi
300 Locations
Up to 20
350 Locations
3 times at 5 minutes intervals
Up to 500 pages *1
Copy Width
Maximum 210 mm
Automatic 2-sided Copy
Up to 999 pages
25 to 400% (in increments of 1%)
Maximum 1200 x 600 dpi
Colour / Black
Yes / Yes
TWAIN Compliant
(macOS v10.10.5, v10.11.x, v10.12)
WIA Compliant
ICA Compliant
Colour Depth
48 bit colour Processing (Input)
24 bit colour Processing (Output)
Grey Scale
16 bit colour Processing (Input)
8 bit colour Processing (Output)
Resolution *1
Up to 19200 x 19200 dpi (interpolated)
Up to 1200 x 2400 dpi (from Scanner Glass)
Up to 1200 x 600 dpi (from ADF)
Automatic 2-sided Scanning
Automatic 2-sided Print
Emulation
PCL6, BR-Script3, PDF Version 1.7, XPS Version 1.0
600 x 600 dpi, 2,400 dpi class (2400 x 600) quality
Print Speed *1 *2
1-sided print
Up to 33 pages/minute (Letter size)
Up to 31 pages/minute (A4 size)
2-sided Print
Up to 14 sides/minute (Up to 7 sheets/minute) (Letter or A4 size)
First Print Time *3
USB *1 *2
Hi-Speed USB 2.0
Use a USB 2.0 interface cable that is no more than 2.0 metres long.
LAN
10Base-T/100Base-TX/1000Base-T *3 *4
Wireless LAN
IEEE 802.11b/g/n (Infrastructure Mode)
IEEE 802.11g/n (Wi-Fi Direct®)
NFC *5
PDF version1.7, JPEG, Exif+JPEG, PRN (created by own printer driver), TIFF (scanned by Brother models), XPS version 1.0
USB direct interface : Front x 1, Rear x 1(MFC-L9570CDW)
10Base-T/100Base-TX/1000Base-T
IEEE 802.11b/g/n (Infrastructure Mode), IEEE 802.11g/n (Wi-Fi Direct)
ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, POP3, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print/Scan), SNTP Client, LDAP, IMAP4
NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, POP3, SMTP Client, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMPv6, SNTP Client, LDAP, Web Services (Print/Scan), IMAP4
APOP, SMTP-AUTH, SSL/TLS (IPPS, HTTPS, SMTP, POP3, IMAP4), SNMP v3 802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS), Kerberos, IPSec
APOP, SMTP-AUTH, SSL/TLS (IPPS, HTTPS, SMTP, POP3, IMAP4), SNMP v3, 802.1x (LEAP, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS), Kerberos, IPSec
WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES) *1
Wi-Fi Certification Mark License (WPA™/WPA2™ - Enterprise, Personal), Wi-Fi Protected Setup (WPS) Identifier Mark License, Wi-Fi CERTIFIED™ Wi-Fi Direct
Consumables & Accessories
Toner Cartridge
Drum Unit
Waste Toner Box
Belt Unit
