Woox Smart Home Beltéri Kamera
SPECIFICATIONS:
PRODUCT DIMENSION
55 x 55 x 112mm
NET WEIGHT
57 gram
POWER CABLE LENGTH
1 meter
HOUSING MATERIAL
ABS + PC
HOUSING COLOUR
BLACK
INGRESS PROTECTION (IP)
IP20
IMAGE SENSOR
1/3" 2Megapixel Progressive CMOS
SENSOR BRAND AND MODEL
SC2336
MAIN CHIPSET BRAND AND MODEL
AK3918EV330L
WIFI + BT CHIPSET BRAND AND MODEL
6012BX
LENS BRAND AND MODEL
PL057F / 0421
LENS FOCAL LENGTH
4MM
APERTURE
F2.0
ANTENNA GAIN (dBi)
1 dBi
POWER SUPPLY
DC 5V 1A, Type C
LIVE STREAM VIDEO RESOLUTION
HD(2304*1296) / SD(640*360)
NOTIFICATION IMAGE RESOLUTION
SD(640*360)
LIVE STREAM EFFECTIVE PIXELS
3MP
OPTICAL PIXEL OR IMAGE INTERPOLATION
2MP interpolated 3MP
ANGLE OF VIEW (H/V/D)
82°(H) / 45°(V) / 92°(D)
MICROPHONE SENSITIVITY
-40db
NOISE REDUCTION
2D NR
AUDIO INPUT
Built-in Mic
AUDIO OUTPUT
Built in 8Ω1W Speaker
AUDIO COMPRESSION
PCM
VIDEO COMPRESSION
H.265
IR CUT
Support
IR ON/OFF CONTROL
Auto
IR DISTANCE
5 meter
NIGHT VISION MODE
Infrared mode
NUMBER OF INFRARED LAMP BEADS
6 pieces
WIRELESS STANDARD
Wi-Fi IEEE 802.11 b/g/n
WIRELESS FREQUENCY
2400 MHz ~ 2483.5 MHz
WIRELESS ENCRYPTION PROTOCOL
WEP/WPA-PSK/WPA2-PSK
WORKING TEMPERATURE
-10°C~50°C
WORKING HUMIDITY
10~95%RH (no condensation)
PAIRING METHOD
BLE mode, QR code mode
TWO-WAY TALK
SOUND DETECTION
MOTION DETECTION
AREA MONITORING DETECTION
ALARM TIMER SETTINGS
PRIVACY MODE
CLOUD STORAGE
WEB RTC
ANTI FLICKER
LOCAL STORAGE SD SLOT
Up to 128GB (FAT32)
HOT SWAPPABLE SD CARD
VOICE SOLUTION CONFIGURATION
Amazon Alexa, Google Assistant
APPROVED CERTIFICATION
CE-RED, ROHS, REACH
