Interface ports
2 x 2.5-GbE Ethernet
2 x 10-GbE/PoE Ethernet (802.3at, total 30W)
8 x 1-GbE Ethernet
2 x 10-GbE SFP+
USB 3.0 ports
1
Console port
Yes (RJ-45)
Rack-mountable
Yes
Fanless
-
SPI firewall throughput (Mbps)*2
15,000
VPN throughput (Mbps)*3
3,000
IPS throughput (Mbps)*4
6,300
Anti-Malware throughput (Mbps)*4
4,000
UTM throughput (Anti-malware & IPS, Mbps)*4
Max. TCP concurrent sessions*5
2,000,000
Max. concurrent IPsec VPN tunnels*6
1,000
Recommended gateway-to-gateway IPsec VPN tunnels
300
Concurrent SSL VPN users
500
VLAN interface
128
Max. Concurrent devices logins*7
Anti-Malware
IPS
Application Patrol
Web filtering
Reputation Filter
SecuReporter
Sandboxing
Device Insight
Secure WiFi*9
VPN
IKEv2, IPSec, SSL
SSL (HTTPS) inspection
Two-Factor Authentication
Nebula Centralized Management
Power input
100-240V AC, 50/60Hz, 2A max.
Max. power consumption (Watt Max.)
86.7
Heat dissipation (BTU/hr)
235
PoE power budget (watt max.)
30
Item
Dimensions (WxDxH)(mm/in.): 430 x 250 x 43.5/16.93 x 9.84 x 1.71
Weight (kg/lb.): 3.14/6.93
Packing
Dimensions (WxDxH)(mm/in.): 512 x 395 x 162/20.16 x 15.55 x 6.38
Weight (kg/lb.): 4.90/10.81
Included accessories
Power cord
RJ-45 - RS-232 cable for console connection
Rack mounting kit
Operating
Temperature: 0°C to 40°C / 32°F to 104°F
Humidity: 10% to 90% (non-condensing)
Storage
Temperature: -30°C to 70°C / -22°F to 158°F
Humidity: 10% to 90%(non-condensing)
MTBF (hr)
40°C/ 431877.9743 hr
25°C/ 669031.2966 hr
Acoustic noise
16.85dBA on < 25degC Operating Temperature, 47.84dBA on full FAN speed
EMC
FCC Part 15 (Class A)
CE EMC (Class A)
RCM (Class A)
BSMI
Safety
LVD (EN62368-1)
